Performing a Test
62 EasyOne Pro™ / EasyOne Pro™ LAB
When three acceptable maneuvers have been performed, the message Ses-
sion complete! Great Job! appears.
 Click Protocol (d, Fig. 3-24) to display the protocol screen.
Note
If a reduced lung function is determined, the physician
needs to decide if and how to continue the test.
With Menu d, you can display a number of keys and then
return to the FVC acquisition screen with Spirometry, for
example.
Fig. 3-24 Screen after three acceptable expiratory FVC measurements
a
b
c
d
a Toggles between volume-time and test
diagramm
b Current test step
c Click to add an FEV1 measurement
d Click to display the protocol screen
Fig. 3-25 Protocol screen
a
b
c
d
a Current test step
bPre-test value
c Next action
dMenu button
