System Specifications
Hardware specification
System unit
Items Description
Processor Socket  LGA1150
Processor Support  Intel® Xeon® Processor E3-1200 v3 product family
Chipset  Intel® C222 Chipset
LAN Controller  Intel® Ethernet Controller I210
Storage  4x 3.5-inch SATA HDD
 RAID 0/1/10/5 with Intel® Rapid Storage Technology
enterprise
 RAID 0/1/10/5/6 with LSI MegaRAID SAS controller
(optional add-in card)
Media Bay  2x 5.25-inch Bay
 (One DVD Super Multi Drive is included)
Server Management Controller  ASPEED® AST2300
VGA Controller  Integrated in Server Management Controller (16GB RAM)
PCI Express Expansion Slot  PCIE_1 – PCI Express x16 slot, running at x16
 PCIE_2 – PCI Express x8 slot, running at x4
 PCIE_3 – PCI Express x8 slot, running at x1
 PCIE_4 – PCI Express x4 slot, running x1
Memory  Four DDR3L (1600MHz) slots
 Support maximum 32GB
I/O Ports  Front Panel – Two USB 3.0 Ports
 Rear Panel- Serial(COM) port, Six USB 2.0 Ports, VGA
Port, One 1000BASE-T LAN Port, One 10/100BASE-TX
server management LAN port,Three Audio connectors
 Internal I/O - Six SATA ports, One USB 2.0 port
Status LED indicators  Front panel- Power, Hard drive
 Rear panel-Activity & Link status for the LAN ports
Thermal Solution  One Systems Fan
 One Processor Heat Sink Fan
Dimension  175(Width) x 386(Depth) x 360(Height) mm
Weight  12.5 kg (maximum configuration, approximate)
Power Supply Unit  500W power supply module, 80 PLUS Bronze

NEC Express5800/T71f Specifications

General

Brand	NEC
Model	Express5800/T71f
Category	Server
Language	English
