NEC Express5800/T71f - Iscsi Configuration

141 pages

To Next Page

To Previous Page

iSCSI Configuration

Paramete

Description Option

Add an Attempts Press [Enter] for configuration of advanced items.

Delete Attempts Press [Enter] for configuration of advanced items.

Change Attempt Order Press [Enter] for configuration of advanced items.
