Power supply specification
Express5800/T71f supports 500-watts power supply module.
Item Description
Model
FSP500-70EP
Type
500W
Dimensions
Height
Depth
Width
86 mm (3.38 in.)
138 mm (5.43 in.)
150 mm (5.9 in.)
Weight (approximate) 1.483 kg (3.26 lb)
Input requirements
Rated input voltage
Normal line voltage
100–240 VAC
115 VAC, 230 VAC
Line frequency
47–63 Hz
Rated input current Load 10A/100-127Vac, 60Hz
Load 5A/220-240Vac, 50Hz
Inrush current
No damage
Power supply output power
Rated steady state power
Maximum peak power
500W
500W
Operating conditions
Temperature
Humidity (non-condensing)
5–50°C (41–122°F)
Up to 85% relative humidity
