27
NOTE: Utility for RAID card
HDD LED indicator at the Server front won't also light amber in the case an error generated for HDD of RAID
controller follower.
When you'd like to monitor HDD, supervision of HDD can do by downloading. SAS Mega RAID Storage
Manager from the following LSI company web and applying it to a Server:
http://www.lsi.com/Pages/default.aspx
[SUPPORT]→[Find Help][Find Support Documents & Downloads by Product]
"Access our complete library of product documentation and software downloads."
NEC Code NEC Product Name Vendor Vendor Product Name Chip Type
N8103-171
RAID controller
(RAID0/1)
LSI LSI MegaRAID SAS 9240-8i
LSISAS2008
(Falcon)
SAS 6Gb/s
SATA 6Gb/s
N8103-150
RAID controller
(512MB,RAID0/1/5/6)
LSI LSI MegaRAID SAS 9267-8i
LSISAS2208
(Thunderbolt B1)
SAS 6Gb/s
SATA 6Gb/s
RAID
2 1
ACT
top:Blackcable
bottom:Red
cable
ACT
1:Blackcable
2:Redcable
