40
Onboard LAN1 Controller Enable/Disable onboard LAN controller. [Enabled]
Disabled
Onboard LAN #1 I/O ROM Enable/Disable onboard LAN#1 device and
initialize device expansion ROM.
[Enabled]
Disabled
PCI Latency Timer Value to be programmed into PCI Latency Timer
Register.
[32 PCI Bus Clocks]
64 PCI Bus Clocks
96 PCI Bus Clocks
128 PCI Bus Clocks
160 PCI Bus Clocks
192 PCI Bus Clocks
224 PCI Bus Clocks
248 PCI Bus Clocks
VGA Palette Snoop Enable/Disable VGA Palette Registers Snooping. Enabled
[Disabled]
PERR Generation When this item is set to enabled, PCI bus parity erro
(PERR) is generated and is routed to NMI.
Enabled
[Disabled]
SERR Generation When this item is set to enabled, PCI bus system
error (SERR) is generated and is routed to NMI.
Enabled
[Disabled]
PCI Express Settings Press [Enter] for configuration of advanced items.
Relaxed Ordering Enable/Disable PCI Express Device Relaxed
Ordering feature.
Enabled
[Disabled]
Extended Tag When this feature is enabled, the system will allow
device to use 8-bit Tag field as are quester.
Enabled
[Disabled]
No Snoop Enable/Disable PCI Express Device No Snoop
option.
[Enabled]
Disabled
Maximum Payload Set maximum payload for PCI Express Device or
allow system BIOS to select the value.
[Auto]
128 Bytes
256 Bytes
512 Bytes
1024 Bytes
2048 Bytes
4096 Bytes
Maximum Read Request Set maximum Read Request size for PCI Express
Device or allow system BIOS to select the value.
[Auto]
128 Bytes
256 Bytes
512 Bytes
1024 Bytes
2048 Bytes
Extended Synch When this feature is enabled, the system will allow
generation of Extended Synchronization patterns.
Enabled
[Disabled]
Link Training Retry Define the number of Retry Attempts software will
take to retrain the link if previous training attempt
was unsuccessful. Press <+> / <-> keys to increase
or decrease the desired values.
Link Training Timeout (us) Define the number of Microseconds software will
wait before polling 'Link Training' bit in Link Status
register. Press <+> / <-> keys to increase or
decrease the desired values. Value rang is from 10
to 10000 us.
Unpopulated Links When this item is set to 'Disable Link, the system will
operate power save feature for those unpopulated
PCI Express links.
[Keep Link ON]
Disable Link
Restore PCIE Registers When this item is enabled, the system will restore
PCI Express device configuration on S3 resume.
Warning: Enabling this may cause issues with other
hardware after S3 resume.
Enabled
[Disabled]
To Next Page
