NEC Express5800/T71f - Page 63

51
Paramete
r
Description Option
Console Redirection
For COM1/COM2/Serial Port for
Out-of-Band Management/Windows
Emergency Management Services
(EMC)
Select whether to enable console
redirection for specified device.
Console redirection enables users
to manage the system from a
remote location.
Enabeld
[Disabled]
Terminal Type Select a terminal type to be used for
console redirection.
VT100
VT100+
[ANSI]
VT-UTF8
Bits per second Select the baud rate for console
redirection.
9600
19200
38400
57600
[115200]
Data Bits Select the Data Bits. 7
[8]
Parity A parity bit can be sent with the data
bits to detect some transmission
errors.
Even: parity bi is 0 if the num of 1's
in the data bits is even.
Odd: parity bit is0if num of 1's the
data bits is odd.
Mark: parity bit is always 1.
Space: Parity bit is always 0.
Mark and Space Parity do not allow
for error detection.
[None]
Even
Odd
Mark
Space
Stop Bits Stop bits indicate the end of a serial
data packet. (A start bit indicates the
beginning).
The standard setting is 1 stop bit.
Communication with slow devices
may require more than 1 stop bit.
[1]
2
Flow Control Flow control can prevent data loss
from buffer overflow. When sending
data, if the receiving buffers are full,
a 'stop' signal can be sent to stop
the data flow. Once the buffers are
empty, a 'start' signal can be sent to
re-start the flow. Hardware flow
control uses two wires to send
start/stop signals.
[None]
Hardware RTS/CTS
VT-UTF8 Combo Key Support Enable/Disable VT-UTF8 Combo
Key Support.
[Enabled]
Disabled
Recorder Mode When this mode enabled, only text
will be send. This is to capture
Terminal data.
Enabled
[Disabled]
Resolution 100x31 Enables or disables extended
terminal resolution.
Enabled
[Disabled]
Legacy OS Redirection Resolution On Legacy OS, the number of Rows
and Columns supported redirection.
[80x24]
80X25
Putty KeyPad Select function Function Key and
KeyPad on Putty.
[VT100]
LINUX
XTERMR6
SCO
ESCN
VT400
