NEC Series E - Page 47

45
♦ To disconnect from
DATA connection,
either station can
press DATA key.
NOTE: If receiving station is programmed for Auto
Answer, disregard this step.
TO SEND DATA TO A STATION WHILE
INVOLVED IN A VOICE CONVERSATION
WITH
ANOTHER STATION
♦ Originating station
presses DATA key
and dials the Data
port number of the
destination station.
♦ Receiving station presses DATA key.
NOTE: If receiving station is programmed for Auto
Answer, disregard this step.
XXXXRLS
(Time display)
D DTE
XXXXRLS
(Time display)
D DTE
♦ DATA connection
is established while
voice conversation
continues. Voice
conversation can
be disconnected
without affecting
DATA connection.
♦ To disconnect from
DATA connection,
either station can
press DATA key at
any time.
TO SEND DATA TO AN INTERNAL STATION
WHEN NO VOICE COMMUNICATION IS
TAKING PLACE
♦ Originating station
presses DATA
key and dials
receiving station’s
data extension.
XXXXD
(Time display)
DTE
XXXXRLS
(Time display)
D DTE
XXXXRDY
(Time display)
D DTE
