Chapter 8 Disk Array Configuration Setting (S100/S1100/S1200/S1300/S2100/S2200/S2300)
IV-151
(2) Operation
In this dialog, LD binding/unbinding can be performed. The operation can be performed by using the popup
menu (right-click) or the buttons on the screen after selecting a logical disk or free space of RANK. The
encircled alphabets in the screen are described below.
Figure 8-47 LD Individual Bind/Unbind
(A)
(B)
Popup Menu
To Next Page
