uPASS Target | installation guide
28/
6.4 Settings
Click 'View' -> 'Show config sidebar' or press F11 to show the configuration sidebar. In the sidebar the configuration
categories are shown. Expand or collapse the setting panels by clicking on it.
6.4.1 Read data
Configure here which tags should be selected, how to access these tags, what data should be read from these tags and
if a security check should be performed.
By default the reader is configured to select ANY TAG and read its EPC number.
Select NEDAP to read only Nedap tags.
NEDAP DUAL-ID enables the uPASS to search for Nedap vehicle-id tags. When a vehicle-id tag is found, the uPASS
searches for driver-id tags.
Example 1 - Nedap
Read only NEDAP UHF tags:
Figure 24: Read data example 1
Example 2 - Custom
Read only tags with EPC number starting with 99 and read 4 words from user memory. Note that the bit pointer is set to
32 because the EPC memory bank starts with 16-bits CRC and 16-bits PC (protocol control). Therefore the EPC number
starts at bit pointer 32.
Figure 25: Read data example 2
