Pixie service manual
70
FUNCTION TESTS
8.4.1 Preparations
1) Remove maintenace unit.
2) Remove right side panel (see “General
disassembly” on page 31).
3) Fill and insert water tank.
4) Open closing handle.
2
1
3
4
The pressure gauge
adapter must sit
firmly in the capsule
bay.
5) Mount pressure gauge adapter (refer
to page 67).
6) Connect pressure hose to pressure
tester.
7) Place a receptacle under the drain
hose of the pressure tester.
8) Connect mains cable.
9) Switch on coffee machine.
10) After heating up, press the "large cup"
button.
6
7
5
9
10
