Pixie service manual
83
PARTS LIST
10.2 208 Turmix TX160 CH
Pos. Part no. Component Remark
1 0067948 Spare holder 280 left mount.
2 0062590 Holder 280 right, black
3 0067960 Spare side wall 280 blue, packed, 2 pcs.
4 0000394 Rubber feet 10.0 x 1.6mm black SJ-5816
5 0067944 Spare water tank 280 cpl. packed, 6 pcs.
6 0062621 Cover 280 cable EU black
7 0064905 Cover 280 Turmix print: silver
8 0062821 Guide 280 water black
9 0062787 Lock rod 280 chrom.
10 0062592 Caps. contain 280 transp.
11 0067946 Spare drip tray 280 packed
12 0062616 Cup shelf 280 black
13 0067869 Drip plate 280 cpl mount. SK
14 0062641 Cover 280 outlet black
15 0062598 Faceplate 280 outlet, black
16 0062589 Outlet 280 neutral
17 0062977 Casing 280 NBU cpl. mount.
18 0063218 Knee-lever 280 NBU cpl. mount.
19 0062808 Tension spring D = 0,4 x 5,0 x 24,0 Inox
22 0067949 Spare thermobl. 280 230V IEC mount.
23 0061701 O-Ring 3,40 x 1,90 EPDM V3 70 Shore black
24 0067942 Spare electronic 280 230V packed
25 0066981 Cover 280 electronic V2 black
26 0062799 Push-button 280 2x print: symb., black
27 0067957 Spare pump 280 230V IEC mount.
28 0062806 Press. spring 1,10 / Dm 15,00
L=19,7 n=4,5 inox ends flaten./
smoothed
29 0065983 Press. hose 280 cpl. mount. damper, pump-TB
30 0062774 Cover 280 pump black
31 0063063 Flow meter NNSA FM cpl.
32 0062783 Molded tube 280 pump transp., 60 Shore
33 0067947 Spare valve lifter 280 packed
34 0062632 Light cond. 280 right transp. caps contain
36 0062631 Light cond. 280 left transp. caps contain
37 0062628 Light cond. 280 receiver transp. level indicator
38 0062629 Light cond. 280 LED transp. level indicator
39 0062617 Strain relief clamp 280 EU neutral
40 0063121 Line cord M12
H05VV-F3G075/L40/N40/PE95,
assembled
41 0062814 Screw KST/PT 4,0x13 bl. galvan. rd. head Torx-20 (SFS-Remform)
42 0062813 Screw KST/PT 4,0x 6 bl. galvan. rd. head Torx-15 (SFS-Remform)
43 0063142 Spring clip d = 8,0 x 1,0mm Inox
44 0068151 Cable protect. 280 black
