PARTS LIST
10 PARTS LIST
10.1 Nespresso EF 280 / C60 and EF 281 / D60
Pos. Part no. Component Remark
1 0067948 Spare holder 280 left mount.
2 0062590 Holder 280 right, black
3 0067953 Spare side wall 281
light blue, packed, 2 pcs. (D60 EU steel
blue, D60 ZA steel blue)
3 0067958 Spare side wall 280
titanium, packed, 2 pcs. (C60 EU titan,
C60 IL titan, C60 SA titan)
3 0067959 Spare side wall 280
red, packed, 2 pcs., (C60 EU red, C60 IL
red, C60 SA red, C60 ZA red)
3 0067960 Spare side wall 280
blue, packed, 2 pcs. (C60 EU indigo,
C60 SA indigo, C60 IL indigo, C60 ZA
idigo)
3 0067961 Spare side wall 281
alu, packed, 2 pcs. (D60 EU alu, D60 ZA
alu)
3 0067962 Spare side wall 281 yellow, packed, 2 pcs. (D60 ZA lime)
4 0000394 Rubber feet 10.0 x 1.6mm black SJ-5816
5 0067944 Spare water tank 280 cpl. packed,6 pcs.
6 0062621 Cover 280 cable EU black
7 0063073 Cover 280 switch black
8 0062821 Guide 280 water black
9 0062787 Lock rod 280 chrom.
10 0062592 Caps contain 280 transp.
11 0067946 Spare drip tray 280 packed
12 0062616 Cup shelf 280 black
13 0067869 Drip plate 280 cpl. mount. SK
13 0067881 Drip plate 281 cpl. mount. SK
14 0062641 Cover 280 outlet black
14 0062599 Cover 281 outlet black
15 0062598 Faceplate 280 outlet, black
16 0062589 Outlet 280 neutral
17 0062977 Casing 280 NBU cpl. mount.
18 0063218 Knee-lever 280 NBU cpl. mount.
19 0062808
Tension spring
D = 0,4 x 5,0 x 24,0
Inox
22 0067949 Spare thermobl. 280 230V IEC mount.
23 0061701 O-Ring 3,40 x 1,90 EPDM V3 70 Shore black
24 0067942 Spare electronic 280 230V packed
25 0066981 Cover 280 electronic V2 black
26 0062799 Push-button 280 2x print: symb, black
27 0067957 Spare pump 280 230V IEC mount.
28 0062806 Press. spring 1,10 / Dm 15,00
L=19,7 n=4,5 inox ends flaten /
smoothed
29 0065983 Press. hose 280 cpl. mount. damper, pump-TB
30 0062774 Cover 280 pump black
31 0063063 Flow meter NNSA FM cpl.
32 0062783 Molded tube 280 pump transp., 60 Shore
To Next Page
