Nespresso Pixie C - Page 73

Pixie service manual
73
FUNCTION TESTS
5) Insert capsule (Cosi is best suited).
6) Press the "large cup" button again.
7) Wait until the measuring cup contains
20 ml of coffee.
8) Then measure the coffee temperature
approx. 5-10 mm under the coffee out-
let.
The coffee temperature should be
86 °C ± 3 °C (187 °F ± 5.4 °F).
5
6
5 - 10 mm
7
T2 T1
RANGE
-200°C - 1370°C
-328°F - 2498°F
1
REL
HOLD
T1 T2
T1
←
T2
°C/°F
MAX MIN
8
