FOX1024s Moving Light Controller. PAGE: 18
6. Manual-Run Fixture
Fixtures can be manually run after fixtures patched.
6.1 Manually-Run Fixture
Attributes (such as Dimmer, Iris, Pan/Tilt) of selected fixtures can be manually modified by Attribute
Key or Wheel A/B, this operation is called Manual-Run Fixture, which can be operated under running or
programming status.
TIPS:
 There are fixtures selected or given value if the indicators of Fixture Page Key flash.
 Under selecting fixture status, the attribute value is modified if the indicators of fixture Numeric
Keys flash slowly.
 Indicator of the Reference Fixture will flash fast.
*Explanation: Manual-Run Fixture --- means manual control fixtures.
Data of manual-run --- means the data modified by manual-run.
Important: Manual-Run Fixture is the operation of highest priority, its modified attribute value will
cover the value of the running playback and output to the fixtures. The output of
playback will not restore until the manual-run fixtures are cleared.
Operation of Manual-Run Fixture:
1) Select fixtures:
Press Fixture Page Key to enter selecting fixture status, press Numeric Key to select single or
multiple fixtures.
(Press two Numeric Keys at the same time and the fixtures between them will be also selected.
Fixtures can be also selected by “GROUP” function.)
2) Modify Attribute:
Use Attribute Key to Modify attributes such as Dimmer, Pan/Tilt, Colour and Shutter. There are
20 Attribute Keys (in 2 Pages, turned by P2 key), each Attribute Key corresponds to 2
attributes. Use Wheel A/B to modify corresponding attributes after pressing Attribute Key.
Correspondence table of attributes and Wheel A/B:
Key Wheel A Wheel B Key Wheel A Wheel B
1
Dimmer
01-B
11
11-A 11-B
2
Iris Shutter
12
12-A 12-B
3
Pan Tilt
13
13-A 13-B
4
Colour1 Colour2
14
14-A 14-B
5
Zoom Focus
15
15-A 15-B
6
Gobo1 Gobo2
16
16-A 16-B
7
Fun1 Fun2
17
17-A 17-B
8
Speed1 Speed2
18
18-A 18-B
9
Effect Yellow
19
19-A 19-B
10
Cyan Magenta
20
20-A 20-B
