Net.DO Lighting Control Equipment Co.,Ltd http://www.netdo.com.cn
FOX1024s Moving Light Controller. PAGE: 26
For example: Program1.01 only records Pan/Tilt while other channels are empty. Program1.02 only
records Colour with other channels empty. Then in playback, Program1.01 will only control
the moving while Program1.02 will only control the colour, they will not affect each other.
TIPS: In editing programs, the attribute value which is unmodified manually will be empty, LCD will
display “ . ”. Press CLEAR to clear fixture value.
9.3 Clear LTP remaining value in Playback
In playback, LTP channel will be output by the way of “latest value first”, so even the playback fader
is pulled down and the program is closed, the value of LTP channel will remain. Sometimes, in order to
record a clean scene, the remaining value should be cleared.
Steps to clear remaining value are as follows:
Pull down all playback faders to close programs Press CLEAR key to clear the value
9.4 Record Program
9.4.1 “Single-Step Program” and “Multi-Step Program”
There are 2 kinds of program: “Single-Step Program” and “Multi-Step Program” (CHASE).
The program with only 1 Step is called “Single-Step Program”, which is used as Scene.
The program with multiple Steps is called “Multi-Step Program”, which is used as Chase. (The
number of Steps is not limited but it’s decided by the memory of console)
9.4.2 Fast record “Program”
The way of fast recording “Single/Multi-Step Program” under running status is as follow:
*TIPS: It’s suggested to clear LTP remaining value firstly in order to edit a clean scene.
“LOCATE” is suggested in Manual-Run, it will give initial value to all fixture channels to
avoid the affect of other programs in playback. (Unless the superimposed effect is needed)
Steps of recording:
1）Manual-Run to edit lighting effects; (Superimpose and run multiple saved scenes also can do)
2）Press and hold RECORD (select fixtures by fixture Numeric Key)
Press Playback Key to finish recording;
*TIPS: The step in marks ( ) can be skipped, all fixtures will be recorded if it is skipped.
Attribute can also be chosen to record:
Press and hold RECORD (select single or multiple attribute by Attribute Key)
Press Playback Key to finish recording;
*TIPS: The console will only record the manually modified attribute, other attribute will be
empty. Scene that used to superimpose programs can be created by this way.
3）If there are saved programs in the Playback Key when recording, the current program will be
saved as the next step of the existed programs (Normally used to record “Multi-Step Program”)
9.5 Edit Program
Program can be created and edited in Program Menu, every step of “Multi-Step Program” can also
be created, edited and set internal speed in the menu. Steps are as follow:
