Net.DO Lighting Control Equipment Co.,Ltd http://www.netdo.com.cn
FOX1024s Moving Light Controller. PAGE: 4
1. Summary
1.1 Functions
FOX series moving light controller, with microcomputer as core, in adoption of new technology, has
more powerful and humanized functions.
1024 DMX channels, DMX512/1990 standard, Output ports with optical isolated.
Up to 100 intelligent Fixtures or 100 Dimmer/LED can be connected.
Up to 42 channels each Fixture. Fixture Library mode, “R20” Fixture Library compatible.
300 Playback programs. 40 Scenes can be overlapped and output, under flash or latch mode.
Effect generator “SHAPE” is provided to program effects like circle, wave, rainbow etc. Overlap,
deform, spread and symmetry are also supported.
Playback trigger mode selectable: Auto1, Auto2, Music synchronous.
One key “Light Show” is achievable, up to 20 light shows can be saved and used (without PC).
MIDI ports are provided to connect consoles in parallel or receive MIDI code to run “Light
Show”.
LCD display with backlight. 12V operate light (OPTIONAL).
USB port is provided for data backup and update by USB-disk.
1.2 Specifications (VER: 2.5)
FOX1024s
DMX512 Total Channels 1024
MAX Intelligent Fixtures 100
MAX Playback Programs 300
MAX Preset Focus 20
MAX Groups 20
Scene-snapshots 40
Shape-Generator YES
LCD Display Screen YES (Chinese/English)
Synchronous Trigger Mode Auto1, Auto2, Music
Parallel by MIDI, “one key light show” YES
Library Format R20 Format
USB Port YES
Music Control Signal Input Line level input / MIC input
Power Supply Switch Power Supply, AC 100~240V, 50/60Hz
Power 15W
Size 482mm × 440mm × 108 mm
