FOX1024s Moving Light Controller. PAGE: 32
10.2 Run SCENE
Switch Pages by pressing SCENE A / B Function Key，select Scenes to run by 1~20 Numeric Key.
*TIPS1: Press and hold SCENE A / B Function Key for 2 seconds to stop the output of all Scenes.
*TIPS2: When the indicator of A / B Function Key is bright, it means the corresponding page is
currently selected. When the indicator flashes slowly, it means there are Scenes in that
page outputting.
*TIPS3: It’s very convenient to make various lighting effects by superimposing Playbacks and
Scenes.
Modes of Scene Numeric Key:
Scenes in Page A are of LATCH mode, which means multiple scenes can be output
together;
No.1~10 Scenes in Page B are of FLASH mode;
No.11~20 Scenes in Page B are of SWOP mode, only 1 scene can be output at the same
time.
11. Synchronous Parallel Operation
Through MIDI interfaces, Master & Slave consoles can be connected to achieve synchronous parallel
operation, it means the “Slave console” will follow the operation of the “Master console”.
Operation that can be Synchronous: Playback (including: faders, Playback Keys, Page Keys, Go/Stop
Keys &
STEP Key) and Scene.
Operation Steps are as follows:
1) Enter Midi Sync menu to set the Master/Slave status of
the consoles separately, and select the MIDI channel(it has to
be the same channel)
2) Connect “Slave console” to “Master console” with MIDI signal cable.
12. Light Show (Auto Playback)
The console supports “Light Show”(auto playback) in External Time Code & Internal Time Code.
Operation that can be recorded/played: Playback (including: faders, Playback Keys, Page Keys, Go/Stop
Keys &
STEP Key) and Scene.
12.1 External Time Code (MIDI)
Users can connect the console with PC through MIDI
interface (by using USB to MIDI convertor), and record/play
“Light Show” with music by MIDI software (For example:
Cubase) in PC.
Master Console Slave Console
Console
Computer
