E2600 Controller-Drive Tray Installation Guide 104
Table 22 LEDs on the Controller Canister Main Faceplate
Location LED Color On Off
1 Ethernet Connector
1 Link Rate LED
Green There is a 100BASE-T rate. There is a 10BASE-T rate.
2 Ethernet Connector
1 Link Active LED
Green The link is up (LED blinks
when there is activity).
The link is not active.
3 Ethernet Connector
2 Link Rate LED
Green There is a 100BASE-T rate. There is a 10BASE-T rate.
4 Ethernet Connector
2 Link Active LED
Green The link is up (the LED
blinks when there is
activity).
The link is not active.
5 Host Link 1
Service Action
Required LED
Amber At least one of the four
PHYs is working, but
another PHY cannot
establish the same link to
the device connected to the
Host IN port connector.
No link error has occurred.
6 Host Link 1
Service Action
Allowed LED
Green At least one of the four
PHYs in the Host IN port is
working and a link exists to
the device connected to the
IN port connector.
A link error has occurred.
7 Host Link 2
Service Action
Required LED
Amber At least one of the four
PHYs is working, but
another PHY cannot
establish the same link to
the device connected to the
Host IN port connector.
No link error has occurred.
8 Host Link 2
Service Action
Allowed LED
Green At least one of the four
PHYs in the Host IN port is
working and a link exists to
the device connected to the
IN port connector.
A link error has occurred.
9 Battery Service
Action Required
LED
Amber The battery in the controller
canister has failed.
Normal status.
10 Battery Charging
LED
Green The battery is fully
charged. The LED blinks
when the battery is
charging.
The controller canister is
operating without a battery
or the existing battery has
failed.
11 Controller Service
Action Allowed
LED
Blue The controller canister can
be removed safely from the
controller-drive tray.
The controller canister
cannot be removed safely
from the controller-drive
tray.
