Virtual Private Networking
108
N300 Wireless ADSL2+ Modem Router DGN2200v3
The following worksheet identifies the parameters used in this procedure, which are
highlighted in blue. For a blank worksheet, see Plan a VPN on page 105.
Table 6. VPN Tunnel Configuration Worksheet
Parameter Value to Be Entered Field Selection
Connection Name RoadWarrior N/A
Pre-Shared Key 12345678 N/A
Secure Association N/A Main Mode Manual Keys
Perfect Forward secrecy N/A Enabled Disabled
Encryption Protocol N/A DES 3DES
Authentication Protocol N/A MD5 SHA-1
Diffie-Hellman (DH) Group N/A Group 1 Group 2
Key Life in seconds 28800 (8 hours) N/A
IKE Life Time in seconds 3600 (1 hour) N/A
VPN Endpoint Local IPSecID LAN IP Address Subnet Mask FQDN or Gateway
IP (W
AN IP
Address)
Client toGateway N/A N/A Dynamic
Gateway toClient 192.168.3.1 255.255.255.0 22.23.24.25
To configure a client-to-gateway VPN tunnel using the VPN Wizard:
1. Select Advanced >
Advanced - VPN > VPN Wizard.
