Virtual Private Networking
130
N300 Wireless ADSL2+ Modem Router DGN2200v3
The VPN Auto Policy screen displays:
3. Enter these policy settings:
Auto Policy Field Description
General Policy Name GtoG
Remote VPN Endpoint
Address T
ype
Fixed IP Address
Remote VPN Endpoint
Address Data
22.23.24.25
Local LAN Use the default settings.
Remote LAN IP Address Select Subnet address from the drop-down list.
Single/Start IP Address 192.168.3.1
Subnet Mask 255.255.255.0
IKE Direction Initiator and Responder
Exchange Mode Main Mode
Diffie-Hellman (DH) Group Group 2 (1024 Bit)
Local Identity Type Use the default setting.
Remote Identity Type Use the default setting.
Parameters Encryption Algorithm 3DES
Authentication Algorithm MD5
Pre-shared Key 12345678
