NETGEAR GS716T User Manual

10
GS716T and GS724T Gigabit Smart Switches
Note: Refer to the release notes for the GS716T and GS724T Gigabit
Smart Switches for information about issues and workarounds.
GS716T and GS724T Smart Switch Setup
This chapter provides an overview of starting your NETGEAR GS716T and GS724T Smart
Switch and accessing the user interface. It also leads you through the steps to use the Smart
Control Center utility. This chapter contains the following sections:
• Switch Management Interface on page 10
• Connecting the Switch to the Network on page 11
• Switch Discovery in a Network with a DHCP Server on page 12
• Switch Discovery in a Network without a DHCP Server on page 14
• Network Settings Configuration on the Administrative System on page 15
• Web Access on page 16
• Smart Control Center Utilities on page 17
• User Interfaces on page 23
• Interface Naming Convention on page 29
Switch Management Interface
The NETGEAR GS716T and GS724T Smart Switches contains an embedded Web server
and management software for managing and monitoring switch functions. The GS716T and
GS724T functions as a simple switch without the management software. However, you can
use the management software to configure more advanced features that can improve switch
efficiency and overall network performance.
Web-based management lets you monitor, configure, and control your switch remotely using
a standard Web browser instead of using expensive and complicated SNMP software
products. From your Web browser, you can monitor the performance of your switch and
optimize its configuration for your network. You can configure all switch features, such as
VLANs, QoS, and ACLs by using the Web-based management interface.
NETGEAR provides the Smart Control Center utility with this product. This program runs
under Microsoft
®
Windows
®
XP, Windows 2000, or Windows Vista
®
and provides a front end
that discovers the switches on your network segment (L2 broadcast domain). When you
power up your switch for the first time, use the Smart Control Center to discover the switch
and view the network information that has been automatically assigned to the switch by a
DHCP server; or, if no DHCP server is present on the network, use the Smart Control Center
to discover the switch and assign static network information.

NETGEAR GS716T Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Stackable	-
Certification	CE, FCC, VCCI, EN, C-Tick, CCC, CSA, UL/cUL, IEC
Product color	Blue
LED indicators	Activity, Link, Power
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1as, IEEE 802.1s, IEEE 802.1v, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 100BASE-T, 1000BASE-T
Noise level	0 dB
Mean time between failures (MTBF)	567680 h
DHCP features	DHCP client
Security algorithms	802.1x RADIUS, HTTPS, SSL/TLS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14.4 W
MAC address table	16000 entries
Number of static routes	32
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Cables included	AC
Supported network protocols	IP

Weight and Dimensions

Depth	204 mm
Width	440 mm
Height	43 mm
Weight	2570 g
