NETGEAR GS716T User Manual

240
GS716T and GS724T Gigabit Smart Switches
EAP Statistics
Use the EAP Statistics page to display information about EAP packets received on a specific
port.
To display the EAP Statistics page, click the Monitoring  Ports tab, and then click the EAP
Statistics link.
The following table describes the EAP statistics displayed on the screen.
Field Description
Ports Specifies the interface which is polled for statistics.
Frames Received Displays the number of valid EAPOL frames received on the port.
Frames Transmitted Displays the number of EAPOL frames transmitted through the port.
Start Frames Received Displays the number of EAPOL Start frames received on the port.
Logoff Frames Received Displays the number of EAPOL Log off frames that have been received on
the port.
Last Frame Version Displays the protocol version number attached to the most recently
received EAPOL frame.
Last Frame Source Displays the source MAC Address attached to the most recently received
EAPOL frame.
Invalid Frames Received Displays the number of unrecognized EAPOL frames received on this
port.
Length Error Frames Received Displays the number of EAPOL frames with an invalid Packet Body
Length received on this port.

NETGEAR GS716T Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Stackable	-
Certification	CE, FCC, VCCI, EN, C-Tick, CCC, CSA, UL/cUL, IEC
Product color	Blue
LED indicators	Activity, Link, Power
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1as, IEEE 802.1s, IEEE 802.1v, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 100BASE-T, 1000BASE-T
Noise level	0 dB
Mean time between failures (MTBF)	567680 h
DHCP features	DHCP client
Security algorithms	802.1x RADIUS, HTTPS, SSL/TLS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14.4 W
MAC address table	16000 entries
Number of static routes	32
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Cables included	AC
Supported network protocols	IP

Weight and Dimensions

Depth	204 mm
Width	440 mm
Height	43 mm
Weight	2570 g
