NETGEAR GS716T User Manual

249
GS716T and GS724T Gigabit Smart Switches
The page also displays information about the traps that were sent.
Field Description
Log The sequence number of this trap.
System Up Time The time at which this trap occurred, expressed in days, hours, minutes, and
seconds since the last reboot of the switch.
Trap Information identifying the trap.
Click Clear Counters to clear all the counters. This resets all statistics for the trap logs to the
default values.
Event Logs
Use the Event Log page to display the event log, which is used to hold error messages for
catastrophic events. After the event is logged and the updated log is saved in flash memory,
the switch will be reset. The log can hold at least 2,000 entries and is erased when an
attempt is made to add an entry after it is full. The event log is preserved across system
resets.
To access the Event Log page, click the Monitoring
 Logs tab, and then click the Event
Logs link.
The following table describes the Event Log information displayed on the screen.
Field Description
Entry The number of the entry within the event log. The most recent entry is first.
Type Specifies the type of entry.
Filename The GS716T and GS724T source code filename identifying the code that
detected the event.
Line The line number within the source file of the code that detected the event.

NETGEAR GS716T Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Stackable	-
Certification	CE, FCC, VCCI, EN, C-Tick, CCC, CSA, UL/cUL, IEC
Product color	Blue
LED indicators	Activity, Link, Power
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1as, IEEE 802.1s, IEEE 802.1v, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 100BASE-T, 1000BASE-T
Noise level	0 dB
Mean time between failures (MTBF)	567680 h
DHCP features	DHCP client
Security algorithms	802.1x RADIUS, HTTPS, SSL/TLS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14.4 W
MAC address table	16000 entries
Number of static routes	32
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Cables included	AC
Supported network protocols	IP

Weight and Dimensions

Depth	204 mm
Width	440 mm
Height	43 mm
Weight	2570 g
