GS716T and GS724T Gigabit Smart Switches
6. Click Cancel to cancel the configuration on the screen and reset the data on the screen to
the latest value of the switch
7. If you make any configuration changes, click Apply to send the updated configuration to the
switch. Configuration changes take place immediately.
The following table describes the read-only MST port configuration information displayed on
the Spanning Tree CST Configuration page
Field Description
Auto-calculated Port Path
Cost
Displays whether the path cost is automatically calculated (Enabled) or not
(Disabled). Path cost is calculated based on the link speed of the port if the
configured value for Port Path Cost is zero.
Port ID The port identifier for the specified port within the selected MST instance. It
is made up from the port priority and the interface number of the port.
Port Up Time Since Counters
Last Cleared
Time since the counters were last cleared, displayed in Days, Hours,
Minutes, and Seconds.
Port Mode Spanning Tree Protocol Administrative Mode associated with the port or port
channel. Possible values are Enable or Disable.
Port Forwarding State Indicates the current STP state of a port. If enabled, the port state
determines what forwarding action is taken on traffic. Possible port states
are:
• Disabled: STP is currently disabled on the port. The port forwards traffic
while learning MAC addresses.
• Blocking: The port is currently blocked and cannot be used to forward
traffic or learn MAC addresses.
• Listening: The port is currently in the listening mode. The port cannot
forward traffic nor can it learn MAC addresses.
• Learning: The port is currently in the learning mode. The port cannot
forward traffic, however, it can learn new MAC addresses.
• Forwarding: The port is currently in the forwarding mode. The port can
forward traffic and learn new MAC addresses
Port Role Each MST Bridge Port that is enabled is assigned a Port Role for each
spanning tree. The port role will be one of the following values: Root Port,
Designated Port, Alternate Port, Backup Port, Master Port, or Disabled
Port.
Designated Root Root Bridge for the selected MST instance. It is made up using the bridge
priority and the base MAC address of the bridge.
Designated Cost Displays cost of the port participating in the STP topology. Ports with a lower
cost are less likely to be blocked if STP detects loops.
Designated Bridge Bridge Identifier of the bridge with the Designated Port. It is made up using
the bridge priority and the base MAC address of the bridge.
Designated Port Port Identifier on the Designated Bridge that offers the lowest cost to the
LAN. It is made up from the port priority and the interface number of the port.
Click Refresh to update the screen with the latest MST information.

NETGEAR GS716T Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Stackable	-
Certification	CE, FCC, VCCI, EN, C-Tick, CCC, CSA, UL/cUL, IEC
Product color	Blue
LED indicators	Activity, Link, Power
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1as, IEEE 802.1s, IEEE 802.1v, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 100BASE-T, 1000BASE-T
Noise level	0 dB
Mean time between failures (MTBF)	567680 h
DHCP features	DHCP client
Security algorithms	802.1x RADIUS, HTTPS, SSL/TLS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14.4 W
MAC address table	16000 entries
Number of static routes	32
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Cables included	AC
Supported network protocols	IP

Weight and Dimensions

Depth	204 mm
Width	440 mm
Height	43 mm
Weight	2570 g
