The following table describes the detailed port information displayed on the screen. To view
information about a different port, select the port number from the Interface menu.
Field Description
Interface Use the drop down menu to select the interface for which data is to be
displayed or configured.
MST ID Displays the created or existing MSTs.
ifIndex This field indicates the ifIndex of the interface table entry associated with this
port on an adapter.
Port Type For most ports this field is blank. Otherwise the possible values are:
• Mirrored: Indicates that the port has been configured as a monitoring
port and is the source port in a port mirroring session. For additional
information about port monitoring and probe ports, see
Multiple Port
Mirroring on page 250.
• Probe: Indicates that the port has been configured as a monitoring port
and is the destination port in a port mirroring session. For additional
information about port monitoring and probe ports, see
Multiple Port
Mirroring on page 250.
• Port Channel: Indicates that the port has been configured as a member
of a port-channel, which is also known as a link Aggregation Group (LAG).
Port Channel ID If the port is a member of a port channel, the port channel's interface ID and
name are shown. Otherwise, Disable is shown.
Port Role Each MST Bridge Port that is enabled is assigned a Port Role for each
spanning tree. The port role will be one of the following values: Root Port,
Designated Port, Alternate Port, Backup Port, Master Port, or Disabled Port.
STP Mode Displays the Spanning Tree Protocol (STP) Administrative Mode for the port or
LAG. The possible values for this field are:
• Enable: Enables the Spanning Tree Protocol for this port.
• Disable: Disables the Spanning Tree Protocol for this port.
STP State Displays the port's current state Spanning Tree state. This state controls what
action a port takes on receipt of a frame. If the bridge detects a malfunctioning
port it will place that port into the broken state. The other five states are
defined in IEEE 802.1D:
• Disabled
• Blocking
• Listening
• Learning
• Forwarding
• Broken
Admin Mode Displays the port control administration state:
• Enable: The port can participate in the network (default).
• Disable: The port is administratively down and does not participate in the
network.

NETGEAR GS716T Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Stackable	-
Certification	CE, FCC, VCCI, EN, C-Tick, CCC, CSA, UL/cUL, IEC
Product color	Blue
LED indicators	Activity, Link, Power
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1as, IEEE 802.1s, IEEE 802.1v, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 100BASE-T, 1000BASE-T
Noise level	0 dB
Mean time between failures (MTBF)	567680 h
DHCP features	DHCP client
Security algorithms	802.1x RADIUS, HTTPS, SSL/TLS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14.4 W
MAC address table	16000 entries
Number of static routes	32
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Cables included	AC
Supported network protocols	IP

Weight and Dimensions

Depth	204 mm
Width	440 mm
Height	43 mm
Weight	2570 g
