NETGEAR GS716T User Manual

243
GS716T and GS724T Gigabit Smart Switches
The Memory Log table also appears on the Memory Log page.
Field Description
Total Number of Messages Displays the number of messages the system has logged in memory.
Only the 64 most recent entries are displayed on the page.
Description The log message text, which includes the time the log was recorded.
The rest of the page displays the Memory Log messages. The format of the log message is
the same for messages that are displayed for the message log, persistent log, or console log.
Messages logged to a collector or relay via syslog have the same format as well.
The following example shows the standard format for a log message:
<14> Mar 24 05:34:05 10.131.12.183-1 UNKN[2176789276]:
main_login.c(179) 3855 %% HTTP Session 19 initiated for user admin
connected from 10.27.64.122
The number contained in the angle brackets represents the message priority, which is
derived from the following values:
Priority = (facility value × 8) + severity level.
The facility value is usually one, which means it is a user-level message. Therefore, to
determine the severity level of the message, subtract eight from the number in the angle
brackets. The example log message has a severity level of 6 (informational). For more
information about the severity of a log message, see the Severity Filter description on page
247.
The message was generated on March 24 at 5:34:05 a.m by the switch with an IP address of
10.131.12.183. The component that generated the message is unknown, but it came from
line 179 of the main_login.c file. This is the 3,855
th
message logged since the switch was last
booted. The message indicates that the administrator logged onto the HTTP management
interface from a host with an IP address of 10.27.64.122.
Use the buttons at the bottom of the page to perform the following actions:
• Click Clear to clear the messages out of the buffered log in the memory.
• Click Refresh to update the page with the latest messages in the log.
• Click Cancel to cancel the configuration on the screen and reset the data on the screen
to the latest value of the switch.

NETGEAR GS716T Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Stackable	-
Certification	CE, FCC, VCCI, EN, C-Tick, CCC, CSA, UL/cUL, IEC
Product color	Blue
LED indicators	Activity, Link, Power
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1as, IEEE 802.1s, IEEE 802.1v, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 100BASE-T, 1000BASE-T
Noise level	0 dB
Mean time between failures (MTBF)	567680 h
DHCP features	DHCP client
Security algorithms	802.1x RADIUS, HTTPS, SSL/TLS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14.4 W
MAC address table	16000 entries
Number of static routes	32
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Cables included	AC
Supported network protocols	IP

Weight and Dimensions

Depth	204 mm
Width	440 mm
Height	43 mm
Weight	2570 g
