The Block Sites page displays.
5. Select a keyword blocking option:
Per Schedule.Turn on keyword blocking according to a schedule that you set. For more information,
see Schedule When to Block Internet Sites and Services on page 46.
Always. Turn on keyword blocking all the time, independent of the Schedule page.
6. In the Type keyword or domain name here field, enter a keyword or domain that you want to block.
For example:
Specify XXX to block http://www.badstuff.com/xxx.html.
Specify .com if you want to allow only sites with domain suffixes such as .edu or .gov.
Enter a period (.) to block all Internet browsing access.
7. Click the Add Keyword button.
The keyword is added to the keyword list. The keyword list supports up to 32 entries.
8. Click the Apply button.
Keyword blocking takes effect.
Delete Keywords From the Blocked List
To delete keywords from the list:
1. Launch a web browser from a computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router user name and password.
The user name is admin.The default password is admin. The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Security > Block Sites.
The Block Sites page displays.
5. Do one of the following:
To delete a single word, select it and click the Delete Keyword button.
The keyword is removed from the list.
To delete all keywords on the list, click the Clear List button.
All keywords are removed from the list.
6. Click the Apply button.
Your settings are saved.
Control Access to the Internet
43
Nighthawk AC2300 Smart WiFi Router

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR Nighthawk R7000P and is the answer not in the manual?

NETGEAR Nighthawk R7000P Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
3G/4G USB modem compatibility-
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)2225 Mbit/s
WLAN data transfer rate (first band)1625 Mbit/s
WLAN data transfer rate (second band)600 Mbit/s
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports5
Security algorithmsWEP, WPA, WPA2-PSK
Antennas quantity3
Product typeTabletop router
Product colorBlack
LED indicatorsPower
Processor cores2
Processor frequency1000 MHz
Power source typeAC
Weight and Dimensions IconWeight and Dimensions
Depth184.5 mm
Width285 mm
Height50 mm
Weight750 g
