The VLAN tag group is added.
10. Click the Apply button.
Your settings are saved.
Set Up an IPTV Port to Lease an Intranet Port
You can set up the router to create an Internet Protocol television (IPTV) port that can lease an IP address
from your IPTV service provider. Use this feature only if you subscribe to an IPTV service and your IPTV
service requires an intranet address.
Some IPTV ports cannot work behind NAT because the IPTV port requires an IP address within the Internet
service provider's network (intranet address).You can set up a bridge connection from the WAN to one of
the LAN ports.When IPTV is connected through WiFi, the home router also must support the bridging of
the WAN port to the WiFi network name (SSID). The designated LAN port or WiFi name becomes an IPTV
port with direct access to the WAN without going through NAT.
To configure an IPTV port:
1. Launch a web browser from a computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router user name and password.
The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Advanced Setup > VLAN/Bridge Settings.
The VLAN / Bridge Settings page displays.
5. Select the Enable VLAN/Bridge Group check box.
The page expands.
6. Select the By bridge group radio button.
The section expands.
7. Select a Wired Ports check box or a Wireless check box:
If your device is connected to an Ethernet port on the router, select the Wired Ports check box that
corresponds to the Ethernet port on the router to which the device is connected.
If your device is connected to your router’s WiFi network, select the Wireless check box that
corresponds to the router’s WiFi network to which the device is connected.
You must select at least one Wired Ports or Wireless check box.You can select more
than one check box.
Note
8. Click the Apply button.
Your settings are saved.
Network Settings
69
Nighthawk AC2300 Smart WiFi Router

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR Nighthawk R7000P and is the answer not in the manual?

NETGEAR Nighthawk R7000P Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
3G/4G USB modem compatibility-
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)2225 Mbit/s
WLAN data transfer rate (first band)1625 Mbit/s
WLAN data transfer rate (second band)600 Mbit/s
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports5
Security algorithmsWEP, WPA, WPA2-PSK
Antennas quantity3
Product typeTabletop router
Product colorBlack
LED indicatorsPower
Processor cores2
Processor frequency1000 MHz
Power source typeAC
Weight and Dimensions IconWeight and Dimensions
Depth184.5 mm
Width285 mm
Height50 mm
Weight750 g
