NETGEAR Nighthawk R7000P User Manual

Unpack Your Router
Your package contains the Nighthawk AC2300 Smart WiFi Router, the power adapter, and a yellow Ethernet
cable.
Figure 1. Package contents
Attach the Antennas
The router comes with three antennas.
To attach the antennas:
1. Remove the antenna caps from the antenna posts on the router.
2. Align the antennas with the antenna posts on the router.
3. Attach the antennas on the threaded antenna posts.
4. Position the antennas for the best WiFi performance.
We recommend that the center antenna be vertical and that you aim the others outward at 45-degree
angles, as shown.
Hardware Setup
9
Nighthawk AC2300 Smart WiFi Router

NETGEAR Nighthawk R7000P Specifications

General

DSL WAN	No
Ethernet WAN	Yes
3G/4G USB modem compatibility	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	2225 Mbit/s
WLAN data transfer rate (first band)	1625 Mbit/s
WLAN data transfer rate (second band)	600 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	5
Security algorithms	WEP, WPA, WPA2-PSK
Antennas quantity	3
Product type	Tabletop router
Product color	Black
LED indicators	Power
Processor cores	2
Processor frequency	1000 MHz
Power source type	AC

Weight and Dimensions

Depth	184.5 mm
Width	285 mm
Height	50 mm
Weight	750 g
