To set up the router in bridge mode:
1. Make a note of the WiFi settings of the other router to which this router will connect.
You must know the SSID, WiFi security mode, wireless password, and operating frequency (either 2.4
GHz or 5 GHz).
2. Launch a web browser from a computer or mobile device that is connected to the network.
3. Enter http://www.routerlogin.net.
A login window opens.
4. Enter the router user name and password.
The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
5. Select ADVANCED > Advanced Setup > Router/ AP / Bridge Mode.
The Router / AP / Bridge Mode page displays.
6. Select the Bridge Mode radio button.
The page adjusts.
7. Click the setup bridge mode wireless settings button.
The Wireless Settings window opens.
8. Specify the settings of the other router to which this router will connect:
a. Select the wireless network frequency (2.4 GHz or 5 GHz).
For 802.11ac mode, select 5 GHz.
b. In the Name (SSID) file, enter the wireless network name (SSID).
c. In the Security Options section, select a radio button.
d. If prompted, type the WiFi password (network key) that you use to connect wirelessly to the other
router.
9. Click the Apply button.
The settings for the other router are saved and the Advanced Wireless Settings page displays.
10. Click the Apply button on the Router / AP / Bridge Mode page.
Your settings are saved.
Set Up a Bridge for a Port Group or VLAN Tag Group
Some devices, such as an IPTV, cannot function behind the router’s network address translation (NAT)
service or firewall. Based on what your Internet service provider (ISP) requires, for the device to connect to
the ISP’s network directly, you can enable the bridge between the device and the router’s Internet port or
add new VLAN tag groups to the bridge.
Network Settings
66
Nighthawk AC2300 Smart WiFi Router

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR Nighthawk R7000P and is the answer not in the manual?

NETGEAR Nighthawk R7000P Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
3G/4G USB modem compatibility-
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)2225 Mbit/s
WLAN data transfer rate (first band)1625 Mbit/s
WLAN data transfer rate (second band)600 Mbit/s
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports5
Security algorithmsWEP, WPA, WPA2-PSK
Antennas quantity3
Product typeTabletop router
Product colorBlack
LED indicatorsPower
Processor cores2
Processor frequency1000 MHz
Power source typeAC
Weight and Dimensions IconWeight and Dimensions
Depth184.5 mm
Width285 mm
Height50 mm
Weight750 g
