NETGEAR Nighthawk R7000P User Manual

5. Right-click the USB device and select Map network drive.
6. Select the drive letter to map to the new network folder.
7. Click the Finish button.
The USB storage device is mapped to the drive letter that you specified.
8. To connect to the USB storage device as a different user, select the Connect using different credentials
check box, click the Finish button, and do the following:
a. Type the user name and password.
b. Click the OK button.
The USB storage device is mapped to the drive letter that you specified.
Access a Storage Device That Is Connected to the Router
From a Mac
From a computer or device on the network, you can access a storage device that is connected to the router.
To access the device from a Mac:
1. Connect a USB storage device to a USB port on your router.
If your USB storage device uses a power supply, you must use it when you connect the USB storage
device to the router.
When you connect the USB storage device to the router’s port, it might take up to two minutes before
it is ready for sharing. By default, the USB storage device is available to all computers on your local
area network (LAN).
2. On a Mac that is connected to the network, select Go > Connect to Server.
3. In the Server Address field, enter smb://readyshare.
4. When prompted, select the Guest radio button.
If you set up access control on the router and you allowed your Mac to access the network, select the
Registered User radio button and enter admin for the name and your admin password for the password.
For more information about access control, see View Devices Currently on the Network on page 85.
5. Click the Connect button.
A window automatically opens and displays the files and folders on the USB storage device.
Back Up Windows Computers With ReadySHARE Vault
Your router comes with free backup software for all the Windows computers in your home. Connect a USB
hard disk drive (HDD) to the router for centralized, continuous, and automatic backup.
The following operating systems support ReadySHARE Vault:
Share USB Storage Devices Attached to the Router
94
Nighthawk AC2300 Smart WiFi Router

NETGEAR Nighthawk R7000P Specifications

General

DSL WAN	No
Ethernet WAN	Yes
3G/4G USB modem compatibility	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	2225 Mbit/s
WLAN data transfer rate (first band)	1625 Mbit/s
WLAN data transfer rate (second band)	600 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	5
Security algorithms	WEP, WPA, WPA2-PSK
Antennas quantity	3
Product type	Tabletop router
Product color	Black
LED indicators	Power
Processor cores	2
Processor frequency	1000 MHz
Power source type	AC

Weight and Dimensions

Depth	184.5 mm
Width	285 mm
Height	50 mm
Weight	750 g
