9. Click the OK button.
10. Click the Apply button.
Your settings are saved.
Prepare to Back Up a Large Amount of Data
Before you back up a large amount of data with Time Machine, NETGEAR recommends that you follow this
procedure.
To prepare to back up a large amount of data:
1. Upgrade the operating system of the Mac computer.
2. Verify and repair the backup disk and the local disk.
3. Verify and repair the permissions on the local disk.
4. Set Energy Saver:
a. From the Apple menu, select System Preferences.
The System Preferences window displays.
b. Select Energy Saver.
The Energy Saver page displays.
c. Click the Power Adapter tab.
d. Select the Wake for Wi-Fi network access check box.
e. Click the back arrow to save the changes and exit the screen.
5. Modify your security settings:
a. From the System Preferences window, select Security & Privacy.
The Security & Privacy page displays.
b. Click the Advanced button at the bottom of the page.
If the Advanced button is grayed out, click the lock icon so that you can change the settings.
c. Clear the Log out after minutes of inactivity check box.
d. Click the OK button.
Your settings are saved.
Use Time Machine to Back Up Onto a USB Hard Disk
You can use Time Machine to back up your Mac computers onto a USB hard disk drive (HDD) that is
connected to one of the router’s USB ports.
Share USB Storage Devices Attached to the Router
96
Nighthawk AC2300 Smart WiFi Router

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR Nighthawk R7000P and is the answer not in the manual?

NETGEAR Nighthawk R7000P Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
3G/4G USB modem compatibility-
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)2225 Mbit/s
WLAN data transfer rate (first band)1625 Mbit/s
WLAN data transfer rate (second band)600 Mbit/s
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports5
Security algorithmsWEP, WPA, WPA2-PSK
Antennas quantity3
Product typeTabletop router
Product colorBlack
LED indicatorsPower
Processor cores2
Processor frequency1000 MHz
Power source typeAC
Weight and Dimensions IconWeight and Dimensions
Depth184.5 mm
Width285 mm
Height50 mm
Weight750 g
