NETGEAR ProSafe GSM7224 User Manual

User Manual for the NETGEAR 7200 Series Layer 2 Managed Switch Software
8-110 Switching Commands
202-10009-01_060204
802.1x Port Security This field displays the authentication login list assigned to the
user for 802.1x port security.
users defaultlogin
This command assigns the authentication login list to use for non-configured users when
attempting to log in to the system. This setting is overridden by the authentication login list
assigned to a specific user if the user is configured locally. If this value is not configured, users will
be authenticated using local authentication only.
Format
users defaultlogin <listname>
Mode Global Config
users login
This command assigns the specified authentication login list to the specified user for system login.
The <
user> must be a configured <user> and the <listname> must be a configured login list.
If the user is assigned a login list that requires remote authentication, all access to the interface
from all CLI, web, and telnet sessions will be blocked until the authentication is complete.
Note that the login list associated with the ‘admin’ user can not be changed to prevent accidental
lockout from the switch.
Format
users login <user> <listname>
Mode Global Config
System Utilities
This section describes system utilities.
clear config
This command resets the configuration to the factory defaults without powering off the switch.
The switch is automatically reset when this command is processed. You are prompted to confirm
that the reset should proceed.
Format
clear config

NETGEAR ProSafe GSM7224 Specifications

Performance Specifications

forwarding modes	Store-and-forward
bandwidth	48 Gbps
switch latency	Less than 20 microseconds for 64-byte frames
system memory	64 MB
packet buffer memory	122 KB embedded memory per port
code storage	8 MB
address database size	8, 000 MAC addresses
addressing	48-bit MAC address
number of VLANs	228
number of trunks	6
number of queues	4
acoustic noise	60 dB
heat dissipation	28.24 Btu/hr
mean time between failure	58, 300 hours

Electrical Specifications

power consumption	36 W
input voltage	100-240VAC
input frequency	50-60 Hz

Physical Specifications

width	440 mm
depth	257 mm
height	43 mm

Environmental Specifications

operating temperature	0 to 40° C
storage temperature	-20 to 70° C
operating humidity	90% maximum relative humidity
storage humidity	95% maximum relative humidity
operating altitude	10, 000 ft
storage altitude	10, 000 ft
