Configure Switching
124
ProSAFE 10-Gigabit Smart Managed Switch XS728T and XS748T User Manual
The port priority is set in multiples of 16. The range is 0 to 240. The possible values are 0,
16, 32, 48, 64, 80, 96, 112, 128, 144, 160, 176, 192, 208, 224, or 240. The default value is
128.
13. Click the Apply button.
The updated configuration is sent to the switch. Configuration changes take effect
immediately.
14. To refresh the page with the latest information about the switch, click the Update button.
The following table describes the nonconfigurable information displayed on the page.
View the CST Port Status
Use the Spanning Tree CST Port Status page to display Common Spanning Tree (CST) and
Internal Spanning Tree on a specific port on the switch.
To view the CST port status:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 10.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is password.
The System Information page displays.
5. Select Switching > STP > Advanced > CST Port Status.
Table 26. CST port configuration
Field Description
Port State The forwarding state of this port. The default is Disabled.
Port ID The port identifier for the specified port within the CST. It is made up
from the port priority and the interface number of the port.
Hello Timer The value of the parameter for the CST. The default is 2 seconds.
