Configure Switching
153
ProSAFE 10-Gigabit Smart Managed Switch XS728T and XS748T User Manual
Configure a Multicast Group
You can configure up to 512 static multicast groups. You create a multicast group by adding
a multicast MAC address to a VLAN. The multicast MAC address becomes the group
identifier.
To configure a multicast group:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 10.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is password.
The System Information page displays.
5. Select Switching > Multicast > Static Multicast Address > Multicast Group
Configuration.
6. From the VLAN ID menu, select the VLAN ID.
7. In the Multicast Address field, enter the multicast MAC address that must become the
group identifier.
8. Click the Add button.
Last Querier Address The IP address of the last querier from which a query was snooped on the VLAN.
Last Querier Version The MLD protocol version of the last querier from which a query was snooped on the
VLAN.
Operational Max
Response Time
The maximum response time to be used in the queries that are sent by the snooping
querier.
Table 39. MLD Snooping Querier VLAN Configuration information (continued)
Field Description
