NETGEAR ProSafe XS728T User Manual

Hardware Specifications and Default Settings
371
ProSAFE 28-Port and 48-Port 10-Gigabit Smart Managed Switch Models XS728T and XS748T
Switch Features and Default Settings
Table 73. Switch features and default settings
Feature Sets Supported Default Setting
Auto negotiation/static
speed/duplex
All ports Auto-negotiation
Auto MDI/MDIX N/A Enabled
802.3x flow control/back pressure 1 (per system) Disabled
Port mirroring 1 destination port and 8 source
ports
Disabled
Link aggregation groups (LAGs) Model XS728T supports 12 LAGs.
Model XS748T supports 24 LAGs.
Preconfigured
802.1D spanning tree 1 Disabled
802.1w RSTP 1 Enabled
802.1s spanning tree 16 instances Disabled
Static 802.1Q tagging 512 Default VLAN ID = 1
Learning process Supports static and dynamic MAC
entries
Dynamic learning is enabled by
default
Storm control per each packet
type (unicast, broadcast,
multicast)
All ports Disabled
Jumbo frame All ports Enabled.
Maximum frame size is 10 KB
Number of queues 8 N/A
Port based N/A N/A
802.1p 1 Enabled
DSCP 1 Disabled
Rate limiting All ports Disabled
802.1x All ports Disabled
MAC ACL 164 (shared with IP and IPv6
ACLs)
All MAC addresses allowed
IP ACL 164 (shared with MAC and IPv6
ACLs)
All IP addresses allowed
IPv6 ACL 164 (shared with IP ACL and MAC
ACL)
All IP addresses allowed

NETGEAR ProSafe XS728T Specifications

General

Model	XS728T
Category	Switch
Switching Capacity	560 Gbps
Forwarding Rate	417 Mpps
Ports	24 x 10G SFP+, 4 x 10G Base-T
Management	Web-based, SNMP
Features	ACLs, QoS
Power Supply	Internal 100-240VAC, 50-60Hz
Operating Temperature	0°C to 50°C (32°F to 122°F)
Operating Humidity	90% maximum relative humidity, non-condensing
MAC Address Table Size	32, 000 entries
