6. Configure the MST values:
• MST ID. Specify the ID of the MST to create. The valid values for this are 1 to 15.
• Priority. The bridge priority value for the MST. When switches or bridges are running
STP, each is assigned a priority. After exchanging BPDUs, the switch with the lowest
priority value becomes the root bridge. The bridge priority is a multiple of 4096. The
valid range is 0–61440. The default value is 32768.
• VLAN ID. The menu includes all VLANs that are configured on the switch. You can
select VLANs that must be associated with the MST instance or clear VLANs that are
already associated with the MST instance.
7. Click the Add button.
The MST is added.
For each configured instance, the information described in the following table displays on the
page.
Modify an MST Instance
To modify an MST instance:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 10.
Table 29. MST configuration
Field Description
Bridge Identifier The bridge identifier for the selected MST instance. It is made up using the bridge
priority and the base MAC address of the bridge.
Time Since Topology
Change
The time since the topology of the selected MST instance last changed.
Topology Change Count The number of times that the topology changed for the selected MST instance.
Topology Change The value of the topology change parameter for the switch indicating if a topology
change is in progress on any port assigned to the selected MST instance. It is
either True or False.
Designated Root The bridge identifier of the root bridge. It is made up from the bridge priority and
the base MAC address of the bridge
Root Path Cost Path cost to the designated root for this MST instance.
Root Port Port to access the designated root for this MST instance.
