Monitor the System
308
ProSAFE 10-Gigabit Smart Managed Switch XS728T and XS748T User Manual
6. Click the Update button to refresh the page with the latest information about the switch.
7. Click the Clear button to clear all the statistics counters, resetting all switch summary and
detailed statistics to default values.
The discarded packets count cannot be cleared.
The following table describes the switch statistics displayed on the page.
Table 64. Switch statistics information
Field Description
ifIndex The interface index of the interface table entry associated with the processor of
this switch.
Octets Received The total number of octets of data received by the processor (excluding framing
bits, but including FCS octets).
Unicast Packets Received The number of subnetwork-unicast packets delivered to a higher-layer protocol.
Multicast Packets Received The total number of packets received that were directed to a multicast address.
This number does not include packets directed to the broadcast address.
Broadcast Packets Received The total number of packets received that were directed to the broadcast
address. This does not include multicast packets.
Octets Transmitted The total number of octets transmitted out of the interface, including framing
characters.
Unicast Packets Transmitted The total number of packets that higher-level protocols requested be
transmitted to a subnetwork-unicast address, including those that were
discarded or not sent.
Multicast Packets
Transmitted
The total number of packets that higher-level protocols requested be
transmitted to a multicast address, including those that were discarded or not
sent.
