Rear Panel
DF1906
3-5
Figure 3-2 Rear Panel
To install with the rear panel facing down,
be sure to raise the legs
"
2.2 Installation"
Nomenclature plate
Certification label
Power inlet
POWER Switch
The upper position is on
The lower position is off
