NF DF 1906 - 4 ． Advanced Operations

DF1906
4-1
4． Advanced Operations
4.1 Symmetry and Duty Ratio ································ 4-2
4.1.1 Set Symmetry (Ramp Wave) ······················· 4-2
4.1.2 Set Duty Ratio (Square Wave) ····················· 4-2
4.2 Oscillation Mode-related Settings ······················· 4-3
4.2.1 Set Mark Wave Number ·························· 4-3
4.2.2 Set Space Wave Number ···························· 4-3
4.2.3
Select SYNC OUT Function························· 4-4
4.2.4 Set Phase··············································· 4-4
4.2.5 Select TRIG IN Effective Polarity
(Trigger Oscillation) ··································· 4-5
4.2.6 Select TRIG IN Effective Polarity
(Gate Oscillation)······································ 4-5
4.3 Special Menu ················································ 4-6
4.3.1 Setting Memory ········································ 4-6
4.3.2 Select Output at Power On·························· 4-7
4.3.3 Select Load············································· 4-7
4.3.4 Set by High Level/Low Level ······················· 4-8
