8.5 General Specifications
DF1906
8.5 General Specifications
・ I/O ground
Connect all signal I/O ground by wires to the chassis.
・ Remote interface
USB interface (USB 1.1 full speed)
USB-TMC
・ Power supply
Power supply voltage range 100-240 V ±10%, but 250 V or less
Frequency range 50/60 Hz ± 2 Hz
Power consumption 25 VA o r les s
Overvoltage category II
・ Environmental conditions
Ambient temperature and humidity ranges
Operation guarantee +5 to +35°C, 5 to 85%RH (however, absolute humidity of 1 to
25 g/m
3
, no condensing)
Storage -10 to +50°C, 5 to 95%RH (however, absolute humidity of 1 to
29 g/m
3
, no condensing)
Pollution degree 2
・ Insulation resistance
20 MΩ or more (with 500 V DC, between all power input terminals and chassis)
・ Withstand voltage
AC 1500 V (between all power input terminals and chassis)
・ External Dimensions
216 (W) × 132.5 (H) × 93.5 (D) mm (without protructions)
・ Weight
Approx. 1.2 kg (excluding accessories, weight of the main unit only)
