NF DF 1906 - Standard Event Status Register

5.5 Status System
DF1906
5-18
5.5.2 Standard Event Status Register
Table 5-4 shows the definition of the standard event status register. When a bit in the standard event
status enable register is set to 1, the corresponding bit in the standard event status register becomes
effective, and when any effective bit in that register becomes 1, the ESB bit in the status byte register is
set to 1.
The standard event status register can be read by an *ESR? query.
All bits are cleared by reading the register by an *ESR? query, or by using a *CLS command, or by
turning the power back on. (However, the PON bit is set to 1 when the power is turned back on)
Table 5-4 Definition of Standard Event Status Register
Bit
Weight
Description
PON (7)
128
Power on bit
This is set to 1 at power on. When this is cleared to 0 by reading
the register, it remains 0 until the power is turned back on.
PON (6)
64
User request bit
Always 0 (unused)
CME (5)
32
Command error
When there is a syntax error in the program code, this is set to 1.
EXE (4)
16
Execution error
When the parameter is outside the setting range, or when there is
inconsistency in the setting, this is set to 1.
DDE (3)
8
Equipment definition error
Always 0 (unused)
QYE (2)
4
Query error
When an attempt is made to read data in an empty buffer for
storing response messages or when data is lost in a buffer for
storing response messages, this is set to 1.
RQC (1)
2
Request control
Always 0 (unused)
OPC (0)
1
Operation complete
When the processing of the OPC command is all finished, this is
set to 1.
* This bit is always 0 with this equipment .
