Docking
23
FIGHTER 1140
AV Shut-off valve
BK/JK Rock collector/Soil collector
BV Non-return valve
ELK Immersion heater
El VVB Electrical hot water heater
NK Level vessel Included with FIGHTER 1140
SF Particle filter Included with FIGHTER 1140
SÄV Safety valve
PG Boiler temperature sensor Included with FIGHTER 1140
FG Flow sensor Included with FIGHTER 1140
VVG Hot water temperature sensor (88) Included with FIGHTER 1140
UG Outdoor temperature sensor Included with FIGHTER 1140
RG Return temperature sensor Included with FIGHTER 1140
VVB/ACK Accumulator with water heater e.g. VPA
VXV Shuttle valve Accessory in VST 11
SV Shunt valve Motor shunt (230V)
Abbreviations
FIGHTER 1140 can be installed in several different
ways, some of which are described below.
Accessories such as equipment for controlling hot
water etc. are ordered separately. The safety equip-
ment must be installed in accordance with current reg-
ulations for all docking options.
