Control36
FIGHTER 1140
NOTE!
Ensure the operating mode is not
changed during quick movement
A key lock can be activated in the main
menus by simultaneously pressing the
plus and the minus buttons. The key sym-
bol will then be shown on the display. The
same procedure is used to deactivate the
key lock.
Key lock
The menu tree shows all the menus. Three different
menu types can be chosen.
Normal, covers the normal user's needs.
Extended, shows all menus except the service
menus.
Service, shows all menus, returns to the previ-
ous menu type 30 minutes after the last button
was pressed.
Changing of menu type is done from menu 8.1.1
Information is presented on the display about the status
of the heat pump and the electric boiler. Menu 1.0 is nor-
mally shown on the display screen. The plus and minus
buttons and the enter button are used to scroll through
the menu system as well as to change the set value in
some menus.
The Plus button is used to move forward to
the next menu on the current menu level
and to increase the value of the parameter
in menus where this is possible.
The minus button is used to move back to
the previous menu on the current menu
level and to decrease value of the parame-
ter in menus where this is possible.
The enter button is used to select sub-
menus of the current menu, to permit para-
meters to be changed and confirm any
changes to parameters. When the menu
number ends with a zero this indicates
there is a sub-menus.
N
U
S
General
Menu name
Menu number
Key lock
Clock
Symbols
Value of the
current parameter
To quickly return to the main menu from sub-menus
press the following:
1. Operating mode button
2. Enter button
Quick movement
