Control48
FIGHTER 1140
Brine in/out temperatureBrine in/out temperature
Menu 5.6 Number of starts
The accumulated number of starts with the compres-
sor is shown here.
82
Number of starts
5.6
U
Menu 5.9 Comp. acc. run time
The accumulated time that the compressor has been
in operation is shown here.
112h
Comp. acc. run time
5.9
U
Menu 5.11 Hot gas temp.
The hot gas temperature is shown in this menu.
104°C
Hot gas temp.
5.11
U
Menu 5.12 Liquide line temp.
The fluid line temperature is shown in this menu.
48.2°C
Liquide line temp.
5.12
U
Menu 5.13 Bulb temperature
The suction gas temperature is shown in this menu.
5.0°C
Bulb temperature
5.13
U
Menu 6.1 Room compensation
A factor is selected here that determines how much
the flow temperature is affected by the difference
between the room temperature and the set room tem-
perature. A higher value gives a greater change. The
value is adjustable between 0.2 and 3.0.
1,0
Room compensation
6.1
Menu 6.2 Heating system
You select here whether the room sensor should acti-
vate system 1 (menu 2.0) or system 2 (menu 3.0).
Shunt 1
Heating system
6.2
Room temp./Settings
Menu 5.14 Condensor out temp.
The heat medium temperature after the condensor is
shown here.
Condensor out temp.
5.14
U
U
U
Menu 5.22 Max temp cond. flow
This menu shows the max permitted temperature for
condenser flow line.
65°C
Max temp cond. flow
5.22
U
Menu 5.23 Return temp max
This menu displays the max permitted return line tem-
perature.
53°C
Return temp max
5.23
U
Menu 5.24 Return
Pressing the enter button returns you to menu 5.0.
Return
5.24
Menu 6.4 Return
Pressing the enter button returns you to menu 6.0.
Return
6.4
Menu 6.3 Set room temp.
Only shown when accesory RG05 is selected in menu
9.2.18.
The value is adjustable between 5 and 40°C.
Factory setting: 20°C
20
Set room temp.
6.3
U
