Technical specifications
71
FIGHTER 1140
Technical specifications 3 x 230 V (only applies to Norway)
Weight (kg) 175 195 200 215 225 230
Type 6 8 10 12 15 17
Difference pressostat LP (bar) +1,5
Starting current, compressor (A) 60 115 138 145 157 165
Max oper. current incl. immersion heater 4 kW (A) 21,9 24,3 26,6 32,3 35,3 39,3
Output, HC pump (W) 75 75 75 170 170 170
Refrigerant quantity (R407C) (kg) 1,7 2,2 2,4 2,4 2,5 2,6
Pressure drop, evaporator (kPa) 21 23 23 19 25 22
Heating medium flow (l/s) 0,13 0,18 0,22 0,26 0,31 0,36
Max temperature (flow- /return pipe) (°C) 60/50
Difference pressostat HP (bar) -7
Connection Brine male Ø (mm) 28 28 28 35 35 35
Max pressure, collector system (bar) 3
Max operating current, compressor (A) 9,5 12 14,3 20,0 23,0 27,0
Max oper. current incl. immersion heater 6 kW (A) 28,2 30,7 33,0 38,7 41,7 45,7
Output, Brine pump (W) 130 170 170 250 250 250
Connection heating medium male Ø (mm) 28
Brine flow (l/s) 0,35 0,48 0,58 0,65 0,75 0,86
Available pressure, collector system (kPa) 40 58 53 70 65 60
Pressure drop, condensor (kPa) 2,6 3,4 3,2 4,4 3,1 4,1
Enclosure class IP 21
Part No 665 010 665 011 665 012 665 013 665 014 665 015
Cut-out value pressostat HP (bar) 27
Operating temperature collector system
(°C) -5 – +20
Cut-out value pressostat LP (bar) 1,5
Delivered/supplied power* at 0/35 °C ** (kW)
6.0/1.3 8.8/1.9 10.3/2.2 11.7/2.5 14.6/3.1 17.0/3.7
IP 21
* Compressor output only.
** Regards brine in temperature / heat medium flow temperature in accordance with EN 255.
Delivered/supplied power* at 0/50 °C ** (kW) 4.8/1.5 7,1/2,2 8,5/2,5 9,9/2,9 12,6/3,6 14,8/4,3
Operating voltage (V) 3 x 230 V + PE 50 Hz
