List of components
FIGHTER 1140
66
1 Miniature circuit breaker
2 EBV-card, Load monitor card
3 * Thermostat
4 Brine connection, in (f)
5 Brine connection, out (r)
6 Terminal block, -X6
7 Service connection, high pressure
8 Switch, 1 – 0 –
9 Terminal block, incoming electricity, -X9
10 * Contactor, immersion heater step 1
11 Starting capacitor, compressor
12 Start relay
14 Operating condensor, compressor
15 ** Outside temperature sensor
16 Heating medium pump
17 Evaporator
18 Condenser
19 * Shuttle valve
24 * Immersion heater
25 * Temperature limiter
26 Motor protection
27 Compressor
29 Relay card with power supply unit
32 Display unit
33 High pressure pressostat
34 CPU-unit, control system
35 Brine pump
41 Low pressure pressostat
42 Service connection, low pressure
48 Expansion valve
52 ** Safety valve, collector side
60 EMC-filter
61 Suppression capacitor
63 ** Particle filter
65 Drying filter
67 * Contactor, immersion heater step 2
69 Contactor
70 Connection, heating flow
71 Connection, heating return
76 Drainage for heating system
77 Venting valve, collector system
85 ** Level vessel
86 Temperature sensor, “BR-f”, brine in
87 Temperature sensor, “BR-r”, brine out
88 Temperature sensor, hot water jacket
89 Temperature sensor, “VB-Flow”, flow
94 Temperature sensor, “VB-r”, return
95 Type plate
96 Type plate, cooling section
97 Soft-start relay
100 Knob, setting “Fuse”
101 Knob, setting “Max electrical output”
102 Knob, “Max boiler temperature setting”
110 Temperature sensor, hot gas
111 Temperature sensor, fluid pipe
112 Temperature sensor, suction gas
141 Temperature sensor, condensor heat medium
153*** Compressorheater
164 Phase sequence monitor
165*** Terminal block X221, compressorheater
* Accessories
** Enclosed
*** 10, 12, 15, 17 kW 3x400 V
The component list refers to all the different types of heat pump. See each component position picture.
