Control
51
Other settings
Menu 8.2.0 Operating mode
Settings regarding auto mode can be made in the sub-
menus to this menu.
Operating mode
8.2.0
Menu 8.2.2 Winter mode temp.
Here you select the average temperature when the
heat pump, in auto mode, shall switch to winter mode.
The circulation pump and immersion heater are acti-
vated. The value is adjustable between 0 and 30 °C.
20°C
Winter mode temp.
8.2.2
Menu 8.2.1 Summer mode temp.
Here you select the average temperature when the
heat pump, in auto mode, shall switch to summer
mode. In summer mode the circulation pump and
immersion heater are blocked, only hot water is pro-
duced. The value is adjustable between 0 and 30 °C.
25°C
Summer mode temp.
8.2.1
U
U
U
Menu 8.2.3 Return
Pressing the enter button returns you to menu 8.2.0
Return
8.2.3
FIGHTER 1140
Menu 8.1.5 Return
Pressing the enter button returns you to menu 8.1.0
Return
8.1.5
Menu 8.3.0 Current limiter
Settings and readings regarding the load monitor are
set on the sub-menus to this menu. NOTE! No func-
tion in a 1-phase installation.
Current limiter
8.3.0
Menu 8.3.5 Max elec. step
The setting selected on the EBV card (2) knob (101) is
shown here.
2
Max elec. step
8.3.5
Menu 8.3.4 Fuse size
The setting selected on the EBV card (2) knob (100) is
shown here.
16 A
Fuse size
8.3.4
Menu 8.3.1 Current phase 1
Shows the measured current from phase 1. If the
value falls below 2.0 A “low” is shown.
3.5 A
Current Phase 1
8.3.1
Menu 8.3.2 Current phase 2
Shows the measured current from phase 2. If the
value falls below 2.0 A “low” is shown.
3.3 A
Current phase 2
8.3.2
Menu 8.3.3 Current phase 3
Shows the measured current from phase 3. If the
value falls below 2.0 A “low” is shown.
3.3 A
Current phase 3
8.3.3
U
U
U
U
U
U
