System Options
5-8 Manual # 42-02-7223 C1
Setting iCentral PC System NIC IP Address
When you open your iCue PC Network Connections, you will see two local area connections. The LAN
Ethernet controls the iCue LAN connection (iView); the System Ethernet controls the iCue System
connection to iBoxes, Serial Hall Calls, and I/O boards and SHOULD NOT BE CHANGED WITH-
OUT CONSULTING MCE.
If you received your iCentral PC from MCE, the NIC addresses for LAN and SYSTEM connec-
tions are already set as shown in the job prints. You DO NOT need to set them.
If you are replacing the SYSTEM NIC card in the iCentral PC with an NIC provided by MCE, fol-
low the instruction included with the NIC.
If you are replacing the SYSTEM NIC card in the iCentral PC with an NIC not provided by MCE,
use the instructions below. These instructions assume you have not changed the factory-default
settings for the network ports. When setting IP Addresses on a PC, do not enter leading zeros
(i.e., .020 is entered as .20).
The following example is for the Windows 10 operating system.
1. Start the PC.
2. From the Start menu, click Control
Panel. When the control panel opens,
select View by: Small Icons (upper
right corner).
3. Double click Network and Sharing
Center to open the Network and Shar-
ing Center dialog. Click Change
Adapter Settings to open the Network
Connections dialog.
4. You will see two connections; one for the System Ethernet and one for the LAN Ether-
net.
5. Double-click the SYSTEM Ethernet Connection icon to open the Local Area Connection
Status dialog.
To Next Page
